Aprašymas

The Microelectromechanical Systems (MEMS) 5-in-1 is a reference device sold as a NIST Reference Material (RM) that contains MEMS test structures on a test chip. The two RM chips (8096 and 8097) provide for both dimensional and material property measurements. RM 8096 was fabricated on a multiuser 1.5 m complementary metal oxide semiconductor (CMOS) process followed by a bulkmicromachining etch. Material properties of the composite oxide layer are reported on the RM Report of Investigation and described within this guide.3 RM 8097 was fabricated using a polysilicon multi-user surface-micromachining MEMS process with a backside etch. The material properties of the first or second polysilicon layer are reported on the RM Report of Investigation and described within this guide.
